Industrial TiAlN Coated M35 Cobalt Twist Drill Bits with Bullet Tip

Specification:

Material: M35 Cobalt High Speed Steel (HSS-E, 5% Cobalt)
Tip Type: Bullet Tip / Pilot Point / Turbo Tip (Start on contact, no walking)
Coating: TiAlN (Titanium Aluminum Nitride) – Dark Purple/Black
Manufacturing Process: 100% Fully Ground
Standard: DIN 338, Jobber Length
Hardness: HRC 65-67
Point Angle: 135° Split Point with Pilot Effect
Shank Type: Straight Shank (Tri-Flat Shank available for non-slip grip)
Application: Stainless Steel, Cast Iron, High-Temperature Alloys, Hardened Steel, Aluminum, Wood, Plastics.
Size Range: 1mm – 13mm, 1/16″ – 1/2″ (Custom sizes available)

Send email to us

Product Detail

Product Tags

m35 cobalt twist drill bits with bullet tip5

Innovative Bullet Tip Design (Pilot Point)

Our M35 Cobalt drill bits feature a specialized Bullet Tip (Step Point) geometry. This advanced design ensures the bit starts drilling immediately on contact without the need for a center punch ("no walking"). It produces cleaner, rounder, and more precise holes with minimal burring, making it ideal for high-precision industrial metalworking.

M35 Cobalt Steel & TiAlN Coating Excellence

Manufactured from premium M35 Cobalt HSS (5% Co), these bits offer superior red-hardness compared to standard M2 bits. The addition of the TiAlN (Titanium Aluminum Nitride) coating provides an ultra-hard surface (up to 3000HV) and exceptional heat resistance (up to 800°C). This combination allows for faster cutting speeds and a service life 5-10 times longer than untreated bits, especially when drilling tough materials like Grade 304/316 stainless steel.

m35 cobalt twist drill bits with bullet tip6

Optimized for Industrial Productivity

The fully ground flute design ensures rapid chip evacuation, reducing friction and heat buildup during continuous operation. Whether you are using a handheld drill or a CNC machine, our TiAlN coated cobalt bits deliver consistent performance. The 135-degree split point reduces required thrust force, allowing for easier penetration into hardened surfaces.

m35 cobalt twist drill bits with bullet tip77

m35 cobalt twist drill bits with bullet tip8

B2B Manufacturing & Wholesale Advantage

As a leading professional tool manufacturer, Jiacheng Tools provides stable, high-quality supply chains for global distributors and wholesalers. We offer:
• Custom Branding (OEM): Laser marking and customized packaging.
• Quality Assurance: Strict QC from raw material to final coating.
• Cost-Effectiveness: Factory-direct pricing with industrial-grade performance to help you gain a competitive edge in the hardware and construction markets.
